8
Two rechargeable or non-rechargeable batteries of AA type
are organized in a battery pack (5), which is placed into the
battery compartment (6) and closed by cover (7). To fix the
cover (7), turn the latch (8) counter clockwise.
The sight has following controls (see figure 2):
 the ON/OFF switch (10) for turning on the reticle
illumination and image intensifier (SA1 on figure 1);
 the DAY/NIGHT handle (9) for setting the switching
mechanism (4) into the day or night operating mode;
 the hand wheel (3) for smooth brightness adjustment
of the reticle;
 the hand wheel (12) for elevation adjustment;
 the screw (13) for windage adjustment.
