Napoleon Fireplaces BGNV40-N User Manual

Page 3

W415-0320 / D / 01.06.07

Pg 2-6 INTRODUCTION

Warnings and Safety Precautions
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
Dimensions

VENTING

Vent Safety Switch
High Limit Switch
Venting Action

8-9

PENINSULA INSTALLATION PROCEDURE

Framing
Bar / Countertop Installation
Brick Panel Installation
Facing

OPEN END INSTALLATION PROCEDURE

Framing
Brick Panel Installation
Facing

SEE-THRU INSTALLATION PROCEDURE

Framing
Brick Panel Installation
Facing

ISLAND INSTALLATION PROCEDURE

Framing
Brick Panel Installation
Facing

GAS SUPPLY CONNECTION

14-17 FINISHING

Mantle Height Locations
Heat shield stand-off removal
Log Placement/Charcoal Embers
Logo Placement
Door Opening and Closing

Upper Louvre Bracket and Hood

Lower Louvre Bracket and Hinge Screen
Louvre Installation
End Door Installation

OPTIONAL BLOWER INSTALLATION

OPERATION / MAINTENANCE

Operating Instructions
Maintenance

ADJUSTMENTS

Pilot Burner Adjustment
Venturi Adjustments

21-22 REPLACEMENTS

Ordering Replacement Parts
Replacement Parts

ACCESSORIES

24-25 TROUBLE SHOOTING GUIDE
26

SERVICE HISTORY

WARNING

• Do not burn wood or other materials in this fireplace.

• Adults and especially children should be alerted to the hazards of high surface temperatures and should stay

away to avoid burns or clothing ignition. Supervise young children when they are in the same room as the
fireplace.

• Due to high temperatures, the fireplace should be located out of traffic and away from furniture and draperies.

• Clothing or other flammable material should not be placed on or near the fireplace.

• Any safety screen or guard removed for servicing must be replaced prior to operating the fireplace.

• It is imperative that the control compartments, burners and circulating blower and its passageway in the fireplace

and venting system are kept clean. The fireplace and its venting system should be inspected before use and at
least annually by a qualified service person. More frequent cleaning may be required due to excessive lint from
carpeting, bedding material, etc. The fireplace area must be kept clear and free from combustible materials,
gasoline and other flammable vapours and liquids.

• Under no circumstances should this fireplace be modified.

• This fireplace must not be connected to a chimney flue pipe serving a separate solid fuel burning appliance.

• Do not use this fireplace if any part has been under water. Immediately call a qualified service technician to inspect

the fireplace and to replace any part of the control system and any gas control which has been under water.

• Do not operate the fireplace with the glass door removed, cracked or broken. Replacement of the glass should be

done by a licensed or qualified service person.

• Do not strike or slam shut the fireplace glass door.

•

This fireplace uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple sup-

plied by Wolf Steel Ltd.

TABLE of CONTENTS

NOTE: changes, other than editorial, are denoted by a vertical line in the margin.

PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE

This manual is related to the following products:

BGNV40-P
