Page 21
21
W415-0320 / D / 01.06.07
Contact your dealer for questions concerning prices and
availability of replacement parts. Normally all parts can be
ordered through your Napoleon dealer or distributor.
#
PART No.
DESCRIPTION
1*
W361-0016
GLOWING EMBERS
2*
W550-0001
CHARCOAL EMBERS
3
W010-0516
BLACK SIDE DOOR c/w GLASS
4
W562-0009
DOOR GASKET (100 INCHES)
5
W010-0454
GLASS W/ GASKET
6*
W385-0245
NAPOLEON LOGO
7
GL-634
BGNV40 LOGSET
8
W135-0153
LOG#1
9
W135-0154
LOG#2
10
W135-0155
LOG#3 -
PIECE
A
11
W135-0156
LOG#3 -
PIECE
B
12
W135-0157
LOG#4
13
W135-0158
LOG#5 -
PIECE
A
14
W135-0159
LOG#5 -
PIECE
B
15
W475-0511
END FIBRE BRICK PANEL -
FOR
BURNER
16
W475-0512
END FIBRE BRICK PANEL -
FOR
BURNER
17
W475-0515
SIDE FIBRE BRICK PANEL -
FOR
BURNER
18
W475-0513
SIDE FIBRE BRICK PANEL -
FOR
BURNER
19
W080-0519
BOTTOM LOUVRE BRACKET
20
W565-0041
SIDE HINGE SCREEN
32
W010-0871
REPLACEMENT BURNER
33
W010-0801
NATURAL GAS PILOT ASSEMBLY
33
W010-0800
PROPANE GAS PILOT ASSEMBLY
34
W455-0069
NATURAL GAS PILOT INJECTOR
34
W455-0067
PROPANE GAS PILOT INJECTOR
35*
W660-0005
BURNER ON/OFF SWITCH
36
W680-0004
THERMOPILE
37
W680-0005
THERMOCOUPLE
38
W240-0006
ELECTRODE
W
/ WIRE
39
W357-0001
PIEZO IGNITER
40
N455-0003
MAIN BURNER ORIFICE -
PROPANE
REPLACEMENTS
When ordering replacement parts always give the follow-
ing information:
1. M
ODEL
& S
ERIAL
N
UMBER
OF
FIREPLACE
2. I
NSTALLATION
DATE
OF
FIREPLACE
3. P
ART
N
UMBER
4. D
ESCRIPTION
OF
PART
5. F
INISH
6. T
OP
OR
REAR
VENT
COMPONENTS COMMON TO ALL UNITS
BURNER COMPONENTS
COMPONENTS UNIQUE TO OPEN END UNIT
COMPONENTS UNIQUE TO SEE-THRU UNIT
21
W475-0516
END FIBRE BRICK PANEL -
FOR
WALL
22
W500-0193
BRICK PANEL RETAINER
23
W200-0114
SIDE DOOR COVER
24
N010-0327
SIDE DOOR HEAT SHIELD
25
W300-0057
END DOOR TEMPERED GLASS ONLY
26
W475-0517
SIDE BRICK PANEL -
FOR
WALL
27
W010-0873
BLACK END DOOR c/w GLASS
28
W500-0192
END BRICK PANEL RETAINER
29
W565-0054
END HINGE SCREEN
30
W585-0126
END DOOR HEAT SHIELD
31
N010-0323
END DOOR COVER
21
W475-0516
END FIBRE BRICK PANEL -
FOR
WALL
28
W500-0192
END BRICK PANEL RETAINER
30
W585-0126
END DOOR HEAT SHIELD
31
N010-0323
END DOOR COVER
COMPONENTS UNIQUE TO PENINSULA UNIT
21
W475-0516
END FIBRE BRICK PANEL -
FOR
WALL
27
W010-0873
BLACK END DOOR c/w GLASS
28
W500-0192
END BRICK PANEL RETAINER
29
W565-0054
END HINGE SCREEN
30
W585-0126
END DOOR HEAT SHIELD
31
N010-0323
END DOOR COVER
COMPONENTS UNIQUE TO ISLAND UNIT
27
W010-0873
BLACK END DOOR c/w GLASS
29
W565-0054
END HINGE SCREEN
*
IDENTIFIES
ITEMS
WHICH
ARE
NOT
ILLUSTRATED
.
FOR
FURTHER
INFORMATION
,
CONTACT
YOUR
NAPOLEON
DEALER
.
