Comet BXD 2530G Pump Exploded View
21
Part # Description Qty Ref # Part # Description Qty
1 CO3202001800 Plug, 1/8” 1 39 CO0009026700 Ring 3
2 CO1215035400 Thermal Valve, 3/8” 1 40 CO1802027600 Spring 3
3 CO1802021700 Spring 1 41 CO2409014100 Piston 3
4 CO3230003100 Thermal Feeler 1 42 CO0403017900 Pump Crankcase 1
5 Not Available O-Ring 1 43 CO3609000500 Screw 4
6 Not Available Thermal Valve Body 1 44 CO1241005700 Low Pressure Packing 3
7 Not Available Thermal Valve Cap 1 45 CO0009030900 Packing Retainer 3
8 CO3202001800 Plug, 1/8” 1 46 CO1210007100 O-Ring 3
9 CO1802022700 Easy-Start Spring 1 47 Not Available Anti-Extrusion Ring 3
10 CO1210046300 O-Ring 1 48 CO1241005900 Packing + Ring 3
11 CO3003003300 Ball 1 50 CO1210014600 O-Ring 2
12 CO1210046300 O-Ring 1 51 CO1209011700 Gasket 1
13 CO3202031900 Easy-Start Plug 1 52 CO3200010200 Oil Discharge Cap 1
14 CO1215058600 Unloader 1 53 Not Available Suction Valve Plug 3
15 CO1817006400 Unloader Knob 1 54 CO0009022400 Ring 3
16 CO1220005800 Suct/Del Valve Assy Kit 3 55 CO1210009300 O-Ring 3
17 CO1210041500 O-Ring 6 56 CO3202029400 Suction Valve Plug Kit 3
18 Not Available Valve Seat 6 57 CO3410031800 Injector Body Kit 1
19 CO3604002800 Suct/Del Valve 6 58 Not Available Injector Body 1
20 Not Available Suct/Del Valve Spring 6 59 CO1210004000 O-Ring 1
21 Not Available Suct/Del Valve Cage 6 60 CO1210004900 O-Ring 1
22 CO1210015100 O-Ring 3 61 CO2409009100 Check Valve Kit 1
23 CO3202023600 Plug 3 62 CO1802019700 Check Valve Spring 1
24 CO2816008800 Piston Washer 1 63 CO2409008600 Check Valve 1
25 CO0436001700 Ball Bearing 1 64 CO1210046000 O-Ring 1
26 CO0001052800 Eccentric Shaft 1 65 CO8102045000 Water Filter 1
27 Not Available O-Ring 1 66 CO1223010900 Wing Nut 1
28 CO0438010300 Ball Bearing 1 67 CO2800051100 Special Coupling 1
29 Not Available Hallow Shaft 1 68 Not Available Pump Manifold 1
30 CO0019003400 Oil Seal 1 69 Not Available Screw 5
31 CO1210056100 O-Ring 1 70 CO1802018000 Spring 1
32 CO3201002700 Oil Sight Glass 1 71 CO3003002600 Ball 1
33 CO1210004800 O-Ring 1 72 Not Available Chemical Coupling 1
34 CO3200013800 Oil Cap 1 73 CO2803043500 Chemical Coupling Kit 1
35 Not Available Support 1 74 CO2803338000 Outlet Coupling 1
36 CO2811000400 Washer 4 100 CO5109066700 Piston Seal Kit 1
37 CO3607011900 Hex Screw 4 101 CO5025002700 Complete Valve Kit 1
38 Not Available Gasket Disk 1
