Reference Manual for the ME103 802.11b ProSafe Wireless Access Point
5-14 Advanced Configuration
August 2003
Note that ME103 diversity is provided only in receive mode, not in transmit mode. The Primary
RF port provides transmit and receive. The Secondary RF port provides receive mode only.
Therefore passive components such as external antennae can be connected to either Primary or
Secondary ME103 RF ports. However, an active device such as bi-directional booster has to be
used on the Primary RF port only. If using one booster on each Primary and Secondary RF port,
the one connected to the Secondary will boost only the receive signals.
Blank Configuration Worksheet
EAP-TLS Configuration Worksheet
EAP-TLS 802.1x Security Settings
WEP Encryption Key Length:
RADIUS Port:
RADIUS Shared Key:
Network LAN IP Network Address Subnet Mask Gateway IP (LAN IP Address)
