User’s Manual U15776EJ1V0UM
10
Option board
(IE-703089-MC-EM1)
By adding this board, the IE-703002-MC can be used as in-circuit
emulator for V850/SC1, V850/SC2, and V850/SC3.
Probe SWEX-144SD-1 Note 1 General-purpose probe made by TOKYO ELETECH CORPORATION
PC interface board
IE-70000-PC-IF-C Note 2
IE-70000-98-IF-C Note 2
IE-70000-PCI-IF-A
IE-70000-CD-IF-A
This board is used to connect the IE-703002-MC to a personal
computer. This board is inserted in the expansion slot of the
personal computer.
IE-70000-PC-IF-C: For IBM PC/AT TM compatible ISA bus
IE-70000-98-IF-C: For PC-9800 series C bus
IE-70000-PCI-IF-A: For PCI bus
IE-70000-CD-IF-A: For PCMCIA socket
Network module
(IE-70000-MC-SV3)
This module is used when a workstation controls the IE-703002-MC
via Ethernet™.
Power adapter
(IE-70000-MC-PS-B)
AC adapter for in-circuit emulator made by NEC Corporation.
Separately-sold hardware
CHAPTER 1 OVERVIEW
The IE-703089-MC-EM1 is an option board for the IE-703002-MC in-circuit emulator. By connecting the IE-
703089-MC-EM1 and IE-703002-MC, hardware and software can be debugged efficiently in system development
using the V850/SC1, V850/SC2, and V850/SC3.
In this manual, the basic setup procedure and switch settings of the IE-703002-MC when the IE-703089-MC-EM1
is connected are described. For the names and functions of the parts of the IE-703002-MC, and for the connection of
elements, refer to the IE-703002-MC User’s Manual (U11595E).
1.1 Hardware Configuration
Notes 1. For further information, contact Daimaru Kogyo Co., Ltd .
Tokyo Electronics Department (TEL +81-3-3820-7112)
Osaka Electronics Department (TEL +81-6-6244-6672)
2. Cannot be used for PC98-NX series
Optional hardware Separately-sold hardware
In-circuit emulator (IE-703002-MC)
