Your Netcomm dealer:
APPLICATIONS & MARKETS
The IG1000 offers a complete communications solution
and is suitable for real time data capture in:
• meter reading
• ticketing
• vending
• point-of-sale
• EFTPOS terminals
• satellite network integrators
• mining
• engineering
• industrial waste
• plant and equipment
• office machinery
• security
• rural
• utilities
• vending
• refrigeration
• air conditioning
• home automation.
Module Product Code: IG1000C50AU
Development Kit Product Code: IG1000 TEST 5V
NetComm Limited ABN 85 002 490 486
PO Box 1200, Lane Cove NSW 2066 Australia.
PHONE (02) 9424 2070 • FAX (02) 9424 2010
EMAIL [email protected] • www.netcomm.com.au
Trademarks and registered trademarks are the property of NetComm Ltd or their respective owners.
Specifications are subject to change without notice. Images shown may vary slightly from the product.
• ITU-T V.92 with PCM upstream rates up to 48 kbps, QuickConnect, and
Modem-on-hold functions
• V.92, V.90, V.34, V.32bis, V.32, V.22 bis, V.22, V.23, and V.21; Bell 212A
and Bell 103
• MNP 10EC(tm) enhanced cellular performance
• V.250 and V.251 commands
• V.22 bis fast connect
• Data compression and error correction
• V.44 data compression for optimal downloading of Internet Web pages
and files
• V.42 bis and MNP 5 data compression
• V.42 LAPM and MNP 2-4 error correction
• Fax modem
• V.17, V.29, V.27 ter, and V.21 channel 2
• EIA/TIA 578 Class 1 and T.31 Class 1.0 commands
• V.80 synchronous access mode supports host-controlled
communication protocols with H.324 interface support
• Upgradeable Flash ROM
• Data/Fax/Voice call discrimination
• Hardware-based modem controller and digital signal processor (DSP)
• Worldwide operation
• Call progress, blacklisting
• External flash ROM includes default values for 29 countries
• Distinctive ring detect
• Caller ID detect
• Off-hook Call Waiting Caller ID detection during data mode in V.92,
V.90, V.34, V.32bis, or V.32
• Telephony/TAM
• Leased Line Functionality
• V.253 commands
• 2-bit and 4-bit Conexant ADPCM, 8-bit linear PCM, and 4-bit IMA
coding
• 8 kHz sample rate
• Concurrent DTMF, ring, and Caller ID detection
• Built-in host/DTE interface with speeds up to 230.4 kbps
• Direct mode.
• Flow control and speed buffering.
• Automatic format/speed sensing.
• Serial async TTL interface, supports speeds up to 230.4 Kbps
• Industry standard pin outs
• +5V or optional +3.3V operation with +5V tolerant digital inputs.
• Typical power consumption 190mA @5V (Operating on-line), 30mA
(Sleep Mode).
• Size 65.6 X 26.6mm, height off base PCB 17mm
SPECIFICATIONS
EMBEDDED V.92 MODEM TECHNOLOGY
INDUSTRIAL MODEM & DEVELOPERS KIT
1 YEAR
WARRANTY
Conditions apply
