26
W415-0583 / B / 05.23.07
# PART NO. DESCRIPTION
1 W135-0275 OUTER ROCKS
2 W135-0304 SINGLE ROCK
3 W135-0277 BOWL
4 GL-655 ROCK SET ASSEMBLY
5 W565-0090 WIRE MESH
6* W390-0002 DOOR LATCH ( EA )
7 W725-0047 NATURAL GAS VALVE - MODULATING
7 W725-0048 PROPANE GAS VALVE - MODULATING
8* W455-0019 NATURAL GAS ORIFICE #43
8* W455-0003 PROPANE GAS ORIFICE #54
9 W680-0005 THERMOCOUPLE **
10 W240-0005 ELECTRODE C / W LEAD
11 W680-0004 THERMOPILE
12 W010- 1194 NATURAL GAS PILOT ASSEMBLY
13 W010- 1201 PROPANE GAS PILOT ASSEMBLY
14* W455-0070 NG PILOT INJECTOR
14* W455-0068 LP PILOT INJECTOR
15* W385-0334 NAPOLEON® LOGO
16 W500-0106 FIRESTOP (2 INCH CLEARANCE)
17 W100-0099 BURNER
18 GD 552 BLOWER
19 W660-0041 SPARK SWITCH
20 W660-0046 TRANSMITTER
21 W660-0045 RECEIVER
22 W190-0017 DC SPARK UNIT CONTROL
23 W300-0086 NIGHT LIGHT GLASS
24 W387-0006 NIGHT LIGHT LAMP
25 W750-0107 NIGHT LIGHT WIRE
26 W290-0080 NIGHT LIGHT LENSE GASKET
27* W361-0027 INSULATION SLEEVE
28 W225-0171 DOOR
29* W500-0205 RESTRICTOR
30* W010-1500 GLASS W/ GASKET
44* W573-0007 HI-TEMP SEALANT
45 GD501 HEAT GUARD
46 GA-566 HOT AIR DISTRIBUTION KIT
47* GA-72 HOT AIR EXHAUST KIT
48 GA-70 EXTENSION KIT, 5FT FLEX VENT
49* W010-0370 WALL SUPPORT ASSEMBLY
50* W175-0001 4” COUPLER
51* W175-0013 7” COUPLER
52* W175-0239 CONVERSION KIT - NG TO LP
53* W175-0240 CONVERSION KIT - LP TO NG
54 RFK82 RECTANGLE FACING KIT
55 AFK82 ARCHED FACING KIT
56* RFK82WI WROUGHT IRON FACING KIT
Contact your dealer for questions concerning prices and avail-
ability of replacement parts. Normally all parts can be ordered
through your Napoleon® dealer or distributor.
When ordering replacement parts always give the following
information: 1. M ODEL & S ERIAL N UMBER OF FIREPLACE
2. I NSTALLATION DATE OF FIREPLACE
3. P ART N UMBER
4. D ESCRIPTION OF PART
5. F INISH
FOR WARRANTY REPLACEMENT PARTS
,
A PHOTOCOPY OF
THE ORIGINAL INVOICE WILL BE REQUIRED TO HONOUR
THE CLAIM .
REPLACEMENTS
*
IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED
.
FOR
FURTHER INFORMATION
,
CONTACT YOUR
N
APOLEON
®
DEALER .
REPLACEMENT PARTS
ACCESSORIES
GD220 (5 FT)
31* W010-0397 4” FLEXIBLE ALUMINIUM LINER
- (5 FT ) C / W SPACERS
31* W410-0017 7” FLEXIBLE ALUMINIUM LINER - (5 FT )
GD330 (10 FT)
32* W010-0300 4” FLEXIBLE ALUMINIUM LINER
- (10 FT ) C / W SPACERS
32* W410-0018 7” FLEXIBLE ALUMINIUM LINER - (10 FT )
33* W010-0370 WALL SUPPORT ASSEMBLY
34 PERISCOPE - GD201
35 WALL TERMINAL KIT - GD222R
36* 1/12 TO 7/12 PITCH - GD110
37* 8/12 TO 12/12 PITCH - GD111
38* FLAT ROOF - GD112
39 W490-0073 4/7 INNER/OUTER SLEEVE
40 W670-0006 4/7 TERMINAL
41 W170-0086 STORM COLLAR
42 W010-0453 ROOF SUPPORT
43 W263-0065 / ROOF FLASHING
W263-0066 / ROOF FLASHING
W263-0067 ROOF FLASHING
FLEXIBLE VENT KITS
TERMINAL KITS
ROOF TERMINAL KITS
** WARNING: This is a fast acting thermocouple. It is an integral safety component. Replace only with a fast acting ther-
mocouple supplied by Wolf Steel Ltd.
