Replacements, Gd420 (5 ft), Replacement parts – Napoleon Fireplaces DIRECT VENT MILLIVOLT SYSTEM BGD42N User Manual
Page 25: Accessories, Flexible vent kits terminal kits, Roof terminal kits
25
W415-0533 / E / 02.09.06
#
PART NO. DESCRIPTION
1
W357-0001
PIEZO IGNITER
2
W680-0004
THERMOPILE
3
W680-0005
THERMOCOUPLE
4
W010-0800
NATURAL GAS PILOT ASSEMBLY
4
W010-0801
PROPANE GAS PILOT ASSEMBLY
5
W455-0069
NATURAL GAS PILOT INJECTOR
5
W455-0067
PROPANE GAS PILOT INJECTOR
6
W725-0025
NATURAL GAS VALVE
6
W725-0026
PROPANE VALVE
7*
W385-0245
NAPOLEON LOGO
8*
W750-0112
20FT OF WIRE
9
W010-0864
PAN BURNER
10
GL-658
LOG SET
11*
W361-0016
GLOWING EMBERS
12*
W550-0001
CHARCOAL EMBERS
13*
W550-0002
CHARCOAL LUMPS
14
W135-0297
REAR LOG (#1)
15
W135-0300
LEFT CROSSOVER LOG (#4)
16
W135-0301
CENTER LOG (#5)
17
W135-0302
RIGHT CROSSOVER LOG (#6)
18
W135-0298
SMALL LEFT LOG (#2)
19
W135-0299
SMALL RIGHT LOG (#3)
20
W010-0770
BLACK DOOR
C
/
W
GLASS
21
W455-0026
#38 NATURAL GAS ORIFICE
21
W455-0003
#54 PROPANE GAS ORIFICE
22*
W361-0014
VERMICULITE
23
W500-0028
FIRESTOP SPACER (FLEX VENTING)
24*
W500-0205
RESTRICTOR PLATE
25
W585-0138
VENT HEAT SHIELD
26
W185-0020
GRATE
* GD420 (5 FT)
PART NO.
DESCRIPTION
27
W010-0772
5" FLEXIBLE ALUMINIUM LINER - (5
FT
)
C
/
W
S PA C E R S
27
W730-0012
8" FLEXIBLE ALUMINIUM LINER - (5
FT
)
* GD430 (10 FT)
PART NO.
DESCRIPTION
28
W730-0013
8" FLEXIBLE ALUMINIUM LINER - (10
FT
)
28
W010-0773
5" FLEXIBLE ALUMINIUM LINER - (10
FT
)
C
/
W
SPACERS
29
W010-0810
WALL SUPPORT ASSEMBLY
30
PERISCOPE
- GD401
31
WALL TERMINAL KIT
- GD422
32
1/12 TO 7/12 PITCH
-GD410
32
8/12 TO 12/12 PITCH
-GD411
32
FLAT ROOF
-GD412
PART NO. DESCRIPTION
33
W010-0774
AIR TERMINAL
34
W120-0015
VERTICAL CAP
35
W170-0086
STORM COLLAR
36
W010-0453
ROOF SUPPORT
37
W263-0065 /
ROOF FLASHING
W263-0066 /
W263-0067
#
PART NO. DESCRIPTION
38*
W573-0007
10.3OZ TUBE HIGH TEMP SEALANT
39*
W175-0166
5" COUPLER
39*
W175-0002
8" COUPLER
40
GDL42K
LOUVRE KIT -
UPPER
&
LOWER
-
BLACK
40
GDL42PB
LOUVRE KIT -
UPPER
&
LOWER
-
POLISHED
BRASS
40
GDL42SS
LOUVRE KIT -
UPPER
&
LOWER
-
BRUSHED
STAINLESS
STEEL
41
L42K
LOUVRE KIT -
UPPER
&
LOWER
-
BLACK
41
L42PB
LOUVRE KIT -
UPPER
&
LOWER
-
POLISHED
BRASS
41
L42SS
LOUVRE KIT -
UPPER
&
LOWER
-
BRUSHED
STAINLESS
STEEL
42
GDOI42BG
ORNAMENTAL INSET -
BRUSHED
GOLD
42
GDOI42K
ORNAMENTAL INSET -
BLACK
42
GDOI42G
ORNAMENTAL INSET -
GOLD
42
GDOI42SS
ORNAMENTAL INSET -
STAINLESS
STEEL
43*
W690-0001
MILLIVOLT THERMOSTAT
44*
W660-0010B
REMOTE CONTROL -
ADVANTAGE
44*
W660-0011B
REMOTE CONTROL -
ADVANTAGE
PLUS
45*
W660-0013
MODULATING THERMOSTATIC HAND HELD REMOTE
46*
GD825N
MODULATING VALVE REGULATOR
FOR
W660-0013 -
NG
46*
GD825P
MODULATING VALVE REGULATOR
FOR
W660-0013 -
P
47
W500-0163
FIRESTOP SPACER (RIGID VENTING)
48
GD501
HEAT GUARD
49*
W585-0096
SOFFIT HEAT SHIELD
50*
W010-0810
WALL SUPPORT ASSEMBLY
51*
W175-0170
DURA-VENT ZERO CLEARANCE ADAPTOR
52
W170-0086
VENT PIPE COLLAR
53
W585-0092
VENT PIPE SHIELD
54
GZ550-1KT
BLOWER KIT
55*
GD65
FAN KIT
56*
GD36
THERMOSTATIC SENSOR CONTROL KIT
FOR
USE
WITH
GD
65
ONLY
57*
W500-0033
VARIABLE SPEED SWITCH WALL MOUNTING PLATE
58*
KB35
VARIABLE SPEED SWITCH
59
GA-566
HOT AIR DISTRIBUTION KIT
60*
W690-0005
THERMOSTAT - 110V
FOR
USE
WITH
GA-566
ONLY
61*
GA-70
EXTENSION KIT - 5
FT
62
GA-72
HOT AIR EXHAUST KIT
63*
W175-0211
CONVERSION KIT -
NG
-
LP
63*
W175-0212
CONVERSION KIT -
LP
-
NG
REPLACEMENT PARTS
Contact your dealer for questions concerning prices and
availability of replacement parts. Normally all parts can be
ordered through your Napoleon dealer or distributor.
When ordering replacement parts always give the following
information:
1. M
ODEL
& S
ERIAL
N
UMBER
OF
FIREPLACE
2. I
NSTALLATION
DATE
OF
FIREPLACE
3. P
ART
N
UMBER
4. D
ESCRIPTION
OF
PART
5. F
INISH
FOR
WARRANTY
REPLACEMENT
PARTS
,
A
PHOTOCOPY
OF
THE
ORIGINAL
INVOICE
WILL
BE
REQUIRED
TO
HONOUR
THE
CLAIM
.
REPLACEMENTS
FLEXIBLE VENT KITS
TERMINAL KITS
ACCESSORIES
ROOF TERMINAL KITS
*
IDENTIFIES
ITEMS
WHICH
ARE
NOT
ILLUSTRATED
.
FOR
FURTHER
INFORMATION
,
CONTACT
YOUR
NAPOLEON
DEALER
.
