Newcon Optik LAM 3 IR - Manual (Page 8)

4
Fig. 2 — LAM rear view
11 - Bracket
12 - blocking ring
13 - mode switch
14 - low battery indicator
15 – high / low (working / training modes) power switch
16 - remote button connector
17 - windage adjustment knob, illuminator channel
11
17
16
15 14 13
12
