26
WI1370 XP-400 Installation Instructions
8. How do I remove Keypad Sounder on
Alarm?
The keypad sounder follows the Burg
Output. If you need to remove the Keypad
Sounder, then you must remove the Burg
Output from that zone.
9. Transmitters not responding?
Open Transmitter case - Keypad should
go into X-Mitter Tamper Trouble. If not:
Check Receiver Red LED should be
flashing once approx. once a second.
Check Receiver wiring.
Check Programming of Transmitter ID.
If Keypad does go into X-Mitter Tamper
Trouble, check:
Transmitter point is programmed
correctly.
Transmitter is wired correctly:
If using external switch, make sure it is
wired to point 1, and point 2 is jumped
out.
If using internal reed, make sure J1 is
cut and both Point 1 and Point 2
terminals are jumped out.
10. Keypad LEDs Flicker.
The Keypad is not receiving a POLL from
the Panel.
Check Keypad wiring.
1. The Panel is in the process of being
Uploaded/Downloaded.
2. The panel is powering up. LED’s will
flicker until panel has reset and is
polling the keypad.
3. The connection from the control
panel to the keypad is open.
11. No Keypad Entry Sounder during
Entry Time?
The keypad sounder is turned off with the
A9 command. This command will
silence all Keypad sounds except keypad
sounder on alarm. Enter
A9 to turn
keypad sounds back on.
12. No Keypad Chime?
The keypad sounder is turned off with the
A9 command. This command will
silence all Keypad sounds except keypad
sounder on alarm. Enter
A9 to turn
keypad sounds back on.
