Page 15
8
Installation
RGB 3
(Digital RGB)
RGB 1
R/CR/PR
G/Y
B/CB/PB
HD
VD
L(MONO)
R
L(MONO)
Y
CB/PB
CR/PR
R
L(MONO)
AUDIO 3
AUDIO 2
DVD1/HD1
AUDIO 1
RGB2/ DVD2/ HD2
R
REMOTE
CONTROL
EXTERNAL
CONTROL
CONTROL
LOCK
ON /OFF
VIDEO 1
VIDEO 2
VIDEO 3
VCR or Laser Disc Player
Document Camera
DVD Player
IBM VGA or Compatibles
Personal computer with a
digital RGB output
Signal cable (supplied)
To Mini D-Sub 15 pin connector on the plasma monitor
To video inputs on
the plasma monitor
Monitor adapter for
Macintosh (supplied)
Macintosh or Compatibles
(Desk top type)
