*1 Only when using a graphic accelerator board that is capable of displaying 852
ן480.
*2 Display only 640 lines with the screen center of the vertical orientation located at the center.
*3 The picture is displayed in the original resolution. The picture will be compressed for other signals.
*4 Aspect ratio is 5:4. This signal is converted to a 720 dots
ן768 lines signal.
*5 Normally the RGB select mode suite for the input signals is set automatically. If the picture is not displayed properly, set
the RGB mode prepared for the input signals listed in the table above.
*6 To connect the monitor to Macintosh computer, use the monitor adapter (D-Sub 15-pin) to your computer's video port.
*7 Other screen modes (ZOOM and STADIUM) are available as well.
*8 When viewing a moving picture at a vertical frequency greater than 65Hz, the picture may sometimes be unstable (jumpy).
If this occurs, please set the refresh rate of the external equipment to 60Hz.
*9 CVT standard compliant.
NOTE:
• While the input signals comply with the resolution listed in the table above, you may have to adjust the position and size of the
picture or the fine picture because of errors in synchronization of your computer.
• This monitor has a resolution of 1024 dots
ן768 lines. It is recommended that the input signal should be XGA, wide XGA, or
equivalent.
• With digital input some signals are not accepted.
• The sync may be disturbed when a nonstandard signal other than the aforementioned is input.
• If you are connecting a composite sync signal, use the HD terminal.
• “IBM PC/AT” and “XGA” are registered trademarks of International Business Machines, Inc. of the United States.
• “Apple Macintosh” is a registered trademark of Apple Computer, Inc. of the United States.
Dots ן lines
1024 ן 768
1280 ן 1024
768 ן 576
640 ן 480
1152 ן 864
1400 ן 1050
Vertical
frequency
(Hz)
60.0
60.0
50.0
59.9
60.0
72.0
60.0
75.0
85.0
Horizontal
frequency
(kHz)
49.7
63.9
31.4
31.5
53.7
64.9
65.3
82.3
93.9
NORMAL
(4:3)
YES
YES* 4
YES* 7
YES* 7
YES
YES
YES
YES
YES
ANAMORPHIC
(16:9)
YES* 3
YES
YES* 7
YES* 7
YES
YES
YES
YES
YES
RGB
select* 5
– –
– –
– –
640 ן 480
1152 ן 864
– –
– –
– –
– –
Horizontal
– –
– –
NEG
NEG
POS
POS
NEG
NEG
NEG
Signal Type
Vertical
– –
– –
NEG
NEG
NEG
NEG
POS
POS
POS
Sync Polarity Presence
Horizontal
– –
– –
YES
YES
YES
YES
YES
YES
YES
Vertical
– –
– –
YES
YES
YES
YES
YES
YES
YES
Model
Memory
62
29
31
32
84
85
65
71
72
Work Station
(SGI)
PAL625P
NTSC525P
IDC-3000G
Screen mode
