- 12 -
MES-U INTERNAL AND FIELD WIRING
WIRING DIAGRAM number 150-6240 REV. B
(For PVC or LVC unit with remote or attached electrical)
STEAM CYLINDER
NOTE: SOLID LINES WIRING BY OTHERS
HIGH VOLTAGE
ELECTRODE LEADS
(BY OTHERS OR
INCLUDED WITH
PVC UNIT)
-2 LEADS
FOR SINGLE
PHASE
-3 LEADS
FOR THREE
PHASE
PRIMARY TERMINAL
BLOCK
(provided with
PVC unit)
PRIMARY
POWER
MES-U
CONTROL
BOARD
CURRENT
TRANSFORMER
CHANGE
CYLINDER
LAMP
DRAIN
VALE
FILL
VALVE
HIGH WATER
SENSOR PCB
ON
SWITCH OFF
DRAIN
.187 insulated fast-on
For field connection
3 AMP
FUSE
PRIMARY
CONTACTOR
24 vac
(By Others)
ON/OFF
CONTROLS
24 VAC
INPUT
(By Others)
