M10 x 125mm Screw (53)
M10 x 120mm Bolt (57)
M4 x 25mm Self-
tapping Screw (54)
M10 Washer (65)
M10 Nylon Locknut (67)
M6 Washer (70)
M8 Nylon Locknut (66)
M12 x 90mm Bolt (62)
M8 x 60mm Bolt (58)
M
1
4
x
1
8
0
m
m
B
o
lt
(6
0
)
M10 x 111mm Bolt Set (63)
M10 x 65mm Screw (56)
M14 Washer (68)
M6 x 16mm Screw (51)
M6 x 65mm Screw (59)
M14 Nylon Locknut (50)
M12 Nylon Locknut (64)
See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST near the end of this manual.
Note: Some small parts may
have been preattached. If a part is not in the parts bag, check to see if it has been preattached.
PART IDENTIFICATION CHART
