SSVC-4/6 connector installation
a. Insert each wire into the appropriate hole on the removable
connector plug.
b. Use a small flathead screwdriver to tighten each wire
in place.
c. Insert the connector plug into the socket and lock in place
by tightening captive screws on each side of connector.
See (Figure 4).
The inputs of the SSVC-2/4/6 are the connector terminals
labeled “AMPLIFIER”. The outputs are the connector terminals
labeled “SPEAKERS”. Be sure not to reverse these connections
or the SSVC-2/4/6 will not function properly.
5. Locate the pre-printed Room Labels. Affix the appropriate label
to the recessed area next to the knob on the SSVC-2/4/6 .
9
S P E A K E R S E L E C T I O N / V O L U M E C O N T R O L S Y S T E M
Calculating the Impedance Magnification Setting
Use the following instructions to select the correct switch
setting for the number and type of speakers in your system.
1. Count the number of pairs of speakers you are connecting
to the system.
2. Set the Speaker Pairs switch on the rear panel of the
SSVC-2/4/6 to match the number of pairs of speakers (1, 2,
3/4, 5/6).
6
S P E A K E R S E L E C T I O N / V O L U M E C O N T R O L S Y S T E M
“TECH TIP”
Wire size is
expressed by it's
AWG (American
Wire Gauge)
number. The lower
the AWG number,
the larger the wire,
i.e., 12 AWG wire is
physically larger than
14 AWG.
