HOW TO ASSEMBLE THE
POWER BRUSH

1. Snap together the two interlocking

wands.

2. Push assembled wands into Power

Brush handle socket so that buttons
snap into place.

3. Press cord into channels.
4. Connect power brush cord to hose

connection, aligning angled corners
of plug to receptacle on hose.

5. Snap end of hose into assembled

wands, making sure button lock is
engaged.

6. When ready to use, connect the

hose to the vacuum wall inlet
and plug the electrical cord into any
convenient 120 volt outlet.
Note: When using NuTone CH610
or CH615 Direct Plug Hose with
CI390 or CI395 Series Electrified
Inlets, plugging in the hose also
connects the 120V current.

Button

Wand
Swivel

Cord
Holder
