CC100Master Bridge User’s Guide
40
dconfig
Dump all configurations/settings.
default
Reset all settings to factory default, except Password.
diag
-t
-r
On-line EP connection diagnosis.
-t: downstream SNR diagnosis(from Master to EP)
-r: upstream SNR diagnosis(from EP to Master)
: EP MAC to be diagnosed
dir
Show detail file information resides in flash ROM. Include
‘Working Area’ and ‘Upload Area’, refer
Figure 4 . The listed
filenames are,
‘
bootcode ’: boot loader
‘ sysfw4m ’: system firmware
‘ G1C28H21M ’: Master HCNA driver
‘ G0C28H20Ep ’: 3010 EP HCNA driver
‘ G1C28H21Ep ’: 3110 EP HCNA driver
‘ diagsw ’: 3010 diagnosis utility file
‘ diagsw1 ’: 3110 diagnosis utility file
Accompanying with file id, file version, file date, and file size.
dns
[ -s ] Display or set up DNS server setting.
-s
pri : set up Primary DNS server’s IP
-s sec : set up Secondary DNS server’s IP
exit Close the Telnet console.
quit Close the Telnet console.
ep
[ -c ]
[ -n ]
[ -u ]
Set up the EP Properties Profile related setting values.
: EP Host Limit setting value (0~255), default 255
: EP Note setting value
: EP Upstream Rate setting value ( 0~1563,
*64Kbps), default 0 for unlimited
: designated EP MAC to configure
ephpnareboot
(Smart EP)
-m Reset remote Smart EP device
epstat
(Smart EP)
-m
[ -r ]
Display remote Smart EP port statistics for port
LAN1/LAN2/HCNA.
-r: reset all port statistics counter to 0
epswc
(Smart EP)
-m
[ -t ]
[ -u ]
[ -r ]
[ -d ]
[ -p
[ -l ]
[ -s
/100h /100f>]
[ -f ]]
Display or set up remote Smart EP built-in switch Ethernet
properties
-t: display EP switch settings
-u: display EP switch/port status
-r: reset EP switch
-d: reset EP switch’s eeprom settings to factory default
-p: configure EP port LAN1/LAN2/HCNA
-l: link,
: force current port to link up or down, i.e.
enable/disable current port
-s: current port Ethernet mode setting,
: auto-negotiation mode
<10h/10f/100h/100f> : 10/100Mbps, half/full-duplex mode
-f: current port Ethernet flow-control setting,
: turn on /off flow control
epswigmp
epswqosq
epswqosrate
epswqostc
epswtagvlan
(Smart EP)
-m Refer swigmp , swqosq , swqosrate , swqostc , swtagvlan for the
same functionality, but operate on remote Smart EP with
designated MAC address
filter
[ -s
[ -c ]
[ -a -m ]
[ -t ]
[ -w ]
Display or set up the filter rule set, refer the section “ Allow
Source ” for IP and Subnet Mask setup .
: filter set index, total 16 set (0~15)
: activate or de-activate the rule set
: allow or deny the protocol
