Napoleon Fireplaces GDIZC-N - Manual (Page 2)

2
W415-0223 / E / 03.05.09
Pg 2-4 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
5-7 INSTALLATION
Insert Vent Connection
Chimney Connection
Wall Switch / Thermostat
Gas Pipe Installation
7-8 FINISHING
Trim Extrusion Installation
Log Placement
Door Installation
Mantle Clearances
Logo Placement
Pg 9 OPERATION / MAINTENANCE
Operating Instructions
Maintenance
10 REPLACEMENT BLOWER
11 ADJUSTMENTS
Pilot Burner Adjustment
Vent Restrictions
Venturi Adjustments
12-13 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
Terminal Kits
Accessories
14-15 TROUBLE SHOOTING GUIDE
16 SERVICE HISTORY
NOTE: changes, other than editorial, are denoted by a vertical line in the margin.
WARNING
• The fi replace insert is a vented gas-fi red heater. Do not burn wood or other materials in this fi replace in-
sert.
• Adults and especially children should be alerted to the hazards of high surface temperatures and should
stay away to avoid burns or clothing ignition. Supervise young children when they are in the same room as
the fi replace insert.
• Due to high temperatures, the fi replace insert should be located out of traffi c and away from furniture and
draperies.
• Clothing or other fl ammable material should not be placed on or near the fi replace insert.
• Any safety screen or guard removed for servicing must be replaced prior to operating the fi replace insert.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the
fi replace insert and venting system are kept clean. The fi replace insert and its venting system should be
inspected before use and at least annually by a qualifi ed service person. More frequent cleaning may be
required due to excessive lint from carpeting, bedding material, etc. The fi replace insert area must be kept
clear and free from combustible materials, gasoline and other fl ammable vapours and liquids.
• Under no circumstances should this fi replace insert be modifi ed.
• This fi replace insert must not be connected to a chimney fl ue pipe serving a separate solid fuel burning
appliance.
• Do not use this fi replace insert if any part has been under water. Immediately call a qualifi ed service tech-
nicianto inspect the fi replace insert and to replace any part of the control system and any gas control which
has been under water.
• Do not operate the fi replace insert with the glass door opened, cracked or broken. Replacement of the
glass should be done by a licensed or qualifi ed service person.
• Do not strike or slam shut the fi replace insert glass door.
• This fi replace uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple
supplied by Wolf Steel Ltd.
TABLE of CONTENTS
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
