Isolated left and right channel grounds make it safe for
use with any amplifier.
●
May be used with 4, 6, or 8 ohm speaker systems.
●
Ideal for both home and commercial sound installations.
●
Available colors: White, Bone, Almond, or Black.
●
Proudly made in the USA
●
Ten year parts and labor warranty.
Installation Considerations
The VCS-2D-HP is a Decora-style module and is designed to
use standard Decora-style faceplates and mounting
hardware. Decora faceplates (up to 6-gang) with color-
matched plate screws are available from your Niles dealer.
P-Rings and Electrical Boxes
The mounting depth of the VCS-2D-HP is 2
9/16
”. When
installed, the unit extends 2
5/16
” behind the sheetrock wall
(assuming
1/2
” sheetrock). For installation, you must choose
between a standard light switch plaster ring (p-ring) or a
standard 18 cu. in. (or larger) electrical box. Suitable p-rings
and electrical boxes are available from your Niles dealer or
local electrical supply company. Using the p-ring is best
because it gives you unobstructed access to the full depth
3
* Only required if changing color of unit.
TOOLS REQUIRED
• No. 2 Phillips
Screwdriver
• 1/8" Standard
Slotted Screwdriver
• 1/4" Standard
Slotted Screwdriver
• Wire Stripper
• 5/64" Allen Wrench*
