of attenuation instead of 8. Steps 11-6 attenuate -3 dB per
step; steps 5-2 are -6 dB per step. Step 12 is “full-on” and step
1 is “full-off”. The VCS-2D-HP delivers “POP-FREE” switching
between all steps.
●
Silent When Off – Niles controls completely silence your
speakers when they are at the full-off position
●
Removable Connnectors – The connectors on the VCS-
2D-HP are removable and accommodate up to 14 gauge
speaker wire. The connectors simplify your installation:
• The speaker wires are easier to attach—no heavy
control to hold onto.
• The control may be removed without disconnecting
any wiring.
• ”Wire-Guard” barriers between each connector
terminal reduce the chance of a short-circuit.
●
Mounting depth of only 2
9/16
”. Fits into standard 18 cu. in.
1-gang electrical boxes.
●
Printed circuit board construction uses no hand wiring,
assuring high reliability.
●
Tested Performance – 100% tested, electronically and
acoustically, for frequency response, distortion and power
handling.
