2
W415-0661 / C / 02.20.08
30-31 BGD42CF FINISHING
Door Installation / Removal
Removing Valve Access Door
Glass/Door Replacement
Door Trim
Grate Installation
Log Placement
32 COMMON FINISHING
Glowing Embers
Charcoal Embers
Vermiculite
Charcoal Lumps (BGD42CF Only)
Logo Placement
32 BGD36CFG FINISHING
Glass Burner Installation
BGD36CFG bulb replacement
BGD36CFG lens assembly replacement
33 OPTIONAL BLOWER INSTALLATION
BGD36CF Accessing the Blower
BGD42CF Accessing the Blower
Installing the Blower
34 OPTIONAL FAN INSTALLATION
GD36 THERMOSTATIC SENSOR CONTROL
35 BGD36CFG BURNER SWITCH/WIRING DIAGRAM
36 BGD36CFG LIGHT SWITCH/WIRING DIAGRAM
37 RECEPTACLE WIRING DIAGRAM
38 OPERATION BGD36CF AND BGD42CF
Operating Instructions
Maintenance
39 OPERATION / MAINTENANCE BGD36CFG
40-41 ADJUSTMENTS
Pilot Burner Adjustment
Venturi Adjustment
BGD36CFG Venturi Adjustment
Flame Adjustment
42-44 COMMON REPLACEMENTS
BGD36CF(G) REPLACEMENTS
BGD42CF REPLACEMENTS
45-48 TROUBLE SHOOTING GUIDE
47 SERVICE HISTORY
48 NOTES
PG 4-5 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
Unit Dimensions
Installation Overview
6-19 VENTING
Venting Lengths
Minimum Air Terminal Location Clearances
Typical Minimum and Maximum Vent Lengths
Special Vent Installations
Venting Application Flow Chart
Venting Specifi cations
BGD36CF(G) Pre-Installation Preparation
Removing the Valve Access Door
Door Operation
Rear Exit
Top Exit
19-29 INSTALLATION
Wall and Ceiling Protection
Horizontal Installation
Adjustable Firestop Installation
Vertical Installation
Using Flexible Vent Components
Using Rigid Vent Components
Restricting Vertical Vents (BGD42CF ONLY)
Gas Installation
Optional wall switch installation excluding BGD36CFG
Mobile Home Installation
Framing
Installing Standoffs
BGD36CF(G) Minimum Mantel and Enclosure Clearances
Clean Face Surround Minimum Enclosure Clearances
Optional Clean Face Surround Installation BGD36CF(G) only
Finished Floor Installation
Hearth Installation
Optional Clean Face Trim Kit Installation
BGD42CF Minimum Mantel and Enclosure Clearances
30 BGD36CF FINISHING
Log Placement
Glass/Door Replacement
NOTE: CHANGES, OTHER THAN EDITORIAL, ARE DENOTED BY A VERTICAL LINE IN THE MARGIN.
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
TABLE OF CONTENTS
• Do not burn wood or other materials in this fireplace.
• Adults and especially children should be alerted to the hazards of high surface temperatures and should stay away to avoid
burns or clothing ignition. Supervise young children when they are in the same room as the fireplace.
• Clothing or other flammable material should not be placed on or near the fireplace.
• Due to high temperatures, the fireplace should be located out of traffic and away from furniture and draperies.
• Ensure you have incorporated adequate safety measure to protect infants/toddlers from touching hot surfaces.
• Even after the fireplace is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from hot surfaces. These
screens and guards must be fastened to the floor.
• Any safety screen or guard removed for servicing must be replaced prior to operating the fireplace.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the fireplace and venting
system are kept clean. The fireplace and its venting system should be inspected before use and at least annually by a qualified
service person. More frequent cleaning may be required due to excessive lint from carpeting, bedding material, etc. The fireplace
area must be kept clear and free from combustible materials, gasoline and other flammable vapours and liquids.
• Under no circumstances should this fireplace be modified.
• This fireplace must not be connected to a chimney flue pipe serving a separate solid fuel burning appliance.
• Do not use this fireplace if any part has been under water. Immediately call a qualified service technician to inspect the fireplace
and to replace any part of the control system and any gas control which has been under water.
• Do not operate the fireplace with the glass door removed, cracked or broken. Replacement of the glass should be done by a
licensed or qualified service person.
• Do not strike or slam shut the fireplace glass door.
• This fireplace uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple supplied by Wolf
Steel Ltd.
• Pressure relief doors must be kept closed while the fireplace is operating to prevent exhaust fumes containing carbon monox-
ide, from entering into the home. Temperatures of the exhaust escaping through these openings can also cause the surrounding
combustible materials to overheat and catch fire.
• Only doors / optional fronts certified with the unit are to be installed on the appliance.
!
WARNING
