Page 4: Nxp semiconductors
CBT3126_4
© NXP B.V. 2009. All rights reserved.
Product data sheet
Rev. 04 — 12 October 2009
4 of 13
NXP Semiconductors
CBT3126
Quad FET bus switch
9.
Static characteristics
[1]
All typical values are measured at V
CC
= 5 V; T
amb
= 25
°
C.
[2]
This is the increase in supply current for each input that is at the specified TTL voltage level rather than V
CC
or GND.
[3]
Measured by the voltage drop between the A and the B terminals at the indicated current through the switch. ON resistance is
determined by the lowest voltage of the two (A or B) terminals.
10. Dynamic characteristics
[1]
This parameter is warranted but not production tested. The propagation delay is based on the RC time constant of the typical ON
resistance of the switch and a load capacitance, when driven by an ideal voltage source (zero output impedance).
[2]
t
PLH
and t
PHL
are the same as t
pd
;
t
PZL
and t
PZH
are the same as t
en
;
t
PLZ
and t
PHZ
are the same as t
dis
.
Table 6.
Static characteristics
T
amb
=
−
40
°
C to +85
°
C.
Symbol
Parameter
Conditions
Min
Typ
Max
Unit
V
IK
input clamping voltage
V
CC
= 4.5 V; I
I
=
−
18 mA
-
-
−
1.2
V
V
pass
pass voltage
V
I
= V
CC
= 5.0 V; I
SW
=
−
100
µ
A
-
3.8
-
V
I
I
input leakage current
V
CC
= 5.5 V; V
I
= GND or 5.5 V
-
-
±
1
µ
A
I
CC
supply current
V
CC
= 5.5 V; I
SW
= 0 mA;
V
I
= V
CC
or GND
-
-
3
µ
A
∆
I
CC
additional supply current
control pins; per input;
V
CC
= 5.5 V; one input at 3.4 V,
other inputs at V
CC
or GND
-
-
2.5
mA
C
I
input capacitance
control pins; V
I
= 3 V or 0 V
-
1.7
-
pF
C
io(off)
off-state input/output capacitance
V
O
= 3 V or 0 V; nOE = V
CC
-
3.4
-
pF
R
ON
ON resistance
V
CC
= 4.0 V
V
I
= 2.4 V; I
I
= 15 mA
-
16
22
Ω
V
CC
= 4.5 V
V
I
= 0 V; I
I
= 64 mA
-
5
7
Ω
V
I
= 0 V; I
I
= 30 mA
-
5
7
Ω
V
I
= 2.4 V; I
I
= 15 mA
-
10
15
Ω
Table 7.
Dynamic characteristics
T
amb
=
−
40
°
C to +85
°
C; V
CC
= 4.5 V to 5.5 V; for test circuit see
Symbol
Parameter
Conditions
Min
Max
Unit
t
pd
propagation delay
nA to nB or nB to nA; see
-
0.25
ns
t
en
enable time
nOE to nA or nB; see
1.6
4.5
ns
t
dis
disable time
nOE to nA or nB; see
1.0
5.4
ns
