Quad FET bus switch
6. Functional description
7. Limiting values
[1] The input and output negative voltage ratings may be exceeded if the input and output clamp current ratings are observed.
[2] The package thermal impedance is calculated from JESD51-7.
[3] For SO14 package; P
tot
derates linearly with 8 mW/K above 70
°
C.
[4] For SSOP14, SSOP16 and TSSOP14 packages; P
tot
derates linearly with 5.5 mW/K above 70
°
C.
8. Recommended operating conditions
GND 7 8 ground (0 V)
V
CC
14 16 positive supply voltage
n.c. - 1, 9 not connected
Table 2. Pin description …continued
Symbol Pin Description
SOT108-1 SOT337-1 and SOT402-1 SOT519-1
Table 3. Function selection
H = HIGH voltage level; L = LOW voltage level.
Inputs Switch
nOE
L nA to nB disconnected
H nA to nB connected
Table 4. Limiting values
In accordance with the Absolute Maximum Rating System (IEC 60134).
Symbol Parameter Conditions Min Max Unit
V
CC
supply voltage
−
0.5 +7.0 V
V
I
input voltage [1] −
0.5 +7.0 V
I
SW
switch current continuous current through each switch - 128 mA
I
IK
input clamping current V
I
< 0 V
−
50 - mA
T
stg
storage temperature
−
65 +150
°
C
P
tot
total power dissipation T
amb
=
−
40
°
C to +125
°
C [2]
SO14 package [3] - 500 mW
SSOP14 and SSOP16 package [4] - 500 mW
TSSOP14 package [4] - 500 mW
Table 5. Operating conditions
All unused control inputs of the device must be held at V
CC
or GND to ensure proper device operation.
Symbol Parameter Conditions Min Max Unit
V
CC
supply voltage 4.5 5.5 V
V
IH
HIGH-level input voltage 2.0 - V
V
IL
LOW-level input voltage - 0.8 V
T
amb
ambient temperature operating in free-air
−
40 +85
°
C
