Ftp tcp/ip – Nikon WT-2 User Manual
Page 54
47
IP address
1
Obtain automatically: Off
Address: 192.168.1.2
Mask: 255.255.255.000
DNS
Enable DNS: Off
Gateway
Use gateway: Off
1
In this example, it is assumed that network uses class C private IP addresses and
subnet masks. Address assigned to WT-2 must differ from addresses of server and
wireless LAN adapter. For example, if ftp server is 192.168.1.3, 192.168.1.1 can be
assigned to adapter and 192.168.1.2 to WT-2. All addresses must be in same class.
FTP
TCP/IP
Server
Address: 192.168.1.3
1
Port: 21
Anonymous login
On
PASV mode
Off
User ID
Password
Home folder
2
On
Folder
Use proxy server
Off
1
Enter address assigned ftp server (
44).
2
Photographs are uploaded to folder selected in “Home Directory” tab of “Default FTP
Site Properties” dialog (
45).
