E – 25
Connecting Your PC Or Macintosh Computer
Connecting your PC or Macintosh computer to GT2150 Projector will enable you to project your computer's screen
image for an impressive presentation.
To connect to a PC or Macintosh :
1. Turn off the power to your projector and computer.
2. Use an RGB signal cable (not supplied) to connect your PC or Macintosh computer to the projector.
3. Turn on the projector and the computer.
4. If the projector goes blank after a period of inactivity, it may be caused by a screen saver installed on the
computer.
L/MONO
L/MONO
RGB 2
RGB 1
VIDEO 1
VIDEO 2
S-VIDEO AUDIO OUT
R/Cr G/Y B/Cb
V H/HV
R
L/MONO R
L/MONO R L/MONO R
R
L/MONO R
OUTPUT ANALOG
DVI DIGITAL
DVI DIGITAL
RGB signal cable
(not supplied)
RGB signal cable
(not supplied)
PC Macintosh
For older Macintosh, use a commercially available pin
adapter to connect to your Mac's video port.
Pin adapter for Macintosh
(not supplied)
