Technical specifications
Table 1: BayStack 460-24T-PWR Power over Ethernet Switch technical specifications
Performance specifications
Switch fabric 2.56 Gbps
Frame forward rate (64-byte packets) Up to 3.2 million packets per second (pps) maximum, learned unicast traffic
Port forwarding/filtering performance For 10 Mbps: 14,880 pps maximum
(64-byte packets) For 100 Mbps: 148,810 pps maximum
Address database size 16,000 entries at line rate (32,000 entries without flooding)
Addressing 48-bit MAC address
Frame length 64 to 1518 bytes (IEEE 802.1Q Untagged)
64 to 1522 bytes (IEEE 802.1Q Tagged)
Data rate 10Mbps Manchester encoded or 100 Mb/s 4B/5B encoded
Interface options
10BASE-T/100BASE-TX RJ-45 (8-pin modular) connectors for MDI-X interface
100BASE-FX SC and MT-RJ connectors for switched 100 Mbps (100BASE-FX) connections over
50/125 and 62.5/125 micron multimode fiber optic cable (2 km/6562 ft.
maximum distance)
1000BASE-SX (Shortwave Gigabit Fiber) MDA SC connectors for shortwave 850 nm fiber optic connections over multimode
550 m/1805 ft.) fiber optic cable
1000BASE-LX (Longwave Gigabit Fiber) MDA SC connectors for longwave 1300 nm fiber optic connections over single-mode
(3km/9843 ft.) or multimode (550m/1805 ft.) fiber optic cable
The BayStack 450-1GBIC MDA
supports the following GBICs:
1000BASE-SX Uses shortwave 850 nm fiber optic connectors to connect devices over
multimode (550 m or 1,805 ft) fiber optic cable
1000BASE-LX Uses longwave 1,300 nm fiber optic connectors to connect devices over single
mode (5 km or 3.1 mi) or multimode (550 m or 1,805 ft) fiber optic cable
1000BASE-XD Uses single mode fiber to connect devices over distances up to 40 km
(or 31 mi), depending on the quality of the cable
1000BASE-ZX Uses single mode fiber to connect devices over distances up to 70 km
(or 43 mi), depending on the quality of the cable. The ports on this GBIC
operate only in full-duplex mode
Network protocol and standards compatibility IEEE P802.3af draft-compliant
IEEE 802.3 10BASE-T (ISO/IEC 8802 3,Clause 14)
IEEE 802.3u 100BASE-TX (ISO/IEC 8802-3,Clause 25)
IEEE 802.3u 100BASE-FX (ISO/IEC 8802-3,Clause 26)
IEEE 802.1p (Prioritizing)
IEEE 802.1Q (VLAN Tagging)
IEEE 802.1z (Gigabit)
IETF DiffServ
RFC support RFC 1213 (MIB-II); RFC 1493 (Bridge MIB); RFC 2863 (Interfaces Group MIB)
RFC 2665 (Ethernet MIB); RFC 2737 (Entity MIBv2); RFC 2819 (RMON MIB)
RFC 1757 (RMON); RFC 1271 (RMON); RFC 1157 (SNMP); RFC 2748 (COPS)
RFC 2940 (COPS Clients); RFC 3084 (COPS Provisioning); RFC 2570 (SNMPv3)
RFC 2571 (SNMP Frameworks); RFC 2572 (SNMP Message Processing)
RFC 2573 (SNMPv3 Applications); RFC 2574 (SNMPv3 USM); RFC 2575 (SNMPv3 VACM)
