INTRODUCTION
GENERAL INSTRUCTIONS
1. Combustion and dilution air is brought into the unit
through the fresh air intake collars located on the top
rear of the unit.
2. The combustion air is brought into the firebox through
many small holes in the airwash located at the top and
sides of the opening.
3. The dilution air is introduced high in the firebox above
the baffle to cool the chimney.
4. A single air control regulates the burn rate.
5. Inside the firebox combustion takes place and ex-
hausts out the chimney.
6. The optional blower can be installed to draw fresh
outside air into the home, or, if the house has sufficient
air, then either the NZ150-KT kit or the blower can be
installed inside. In either case heated air from the unit
will circulate the air into your home.
