AIR COOLED CHIMNEY INSTALLATION
1. Remove the knock out.
2. Cut away the insulation to gain access to the ring.
3. Remove the ring secured by four screws.
4. Slide the starter collar through the insulation wrap and
affix using the four screws removed in step 3.
5. Secure the inner liner of the chimney to the fireplace 8"
collar using 3 screws supplied with the starter collar (W170-
0098).
6. Follow the chimney manufacturer's instructions for in-
stalling the chimney.
