SPECIFICATIONS
Design Principle
Linear voltage/current amplification.
Continuous Average Power Output
45 watts per channel RMS at 8 ohms.
70 watts per channel RMS at 4 ohms.
Input Impedance
Approximately 15K ohms
Input Sensitivity
.77V for 8Ω rated output
Overall Voltage Gain
28 dB
Frequency Response
Bandwidth Limited from 10 Hz to 100 kHz
Total Harmonic Distortion
8 Ohms
.05% THD from 20 Hz to 20 kHz @ full rated power
4 Ohms
.06% THD from 20 Hz to 20 kHz @ full rated power
Overall Dimensions
17" wide 2-5/16" high (including feet) 13-1/8" deep
Weight
15 lbs
