Infrared ON indicator
• (yellow)
FUNCTIONS AND INDICATORS
13
• High Light cut off indicator
(blue)
Low Battery Indicator
• (red)
• Power ON indicator
(green)
Strap holder
•
Power ON/OFF
•
switch
IR fixed security
switch
•
Battery House
•
cover
Tripod Thread 1/4"
•
• Focusing Ring
• Objective lens
• I/R illuminator
FUNCTIONS AND INDICATORS
12
Dioptrict adjustment ring
• Eye piece
Desiccant
•
Main body of Nightwiness
