Napoleon Fireplaces GVF40P - Manual (Page 20)

20
W415-0319 / D / 08.03.05
Contact your dealer for questions concerning prices and
availability of replacement parts. Normally all parts can be
ordered through your Napoleon dealer or distributor.
# PART No. DESCRIPTION
1* W361-0016 GLOWING EMBERS
2* W550-0001 CHARCOAL EMBERS
3* GD660 STANDARD WALL SWITCH & 20 FT OF WIRE
4* W385-0245 NAPOLEON LOGO
5 GL-634 BGD40 LOGSET
6 W135-0153 LOG#1
7 W135-0154 LOG#2
8 W135-0155 LOG#3 - PIECE A
9 W135-0156 LOG#3 - PIECE B
10 W135-0157 LOG#4
11 W135-0158 LOG#5 - PIECE A
12 W135-0159 LOG#5 - PIECE B
13 W475-0259 END FIBRE BRICK PANEL - FOR BURNER
14 W475-0260 END FIBRE BRICK PANEL - FOR BURNER
15 W475-0278 SIDE FIBRE BRICK PANEL - FOR BURNER
16 W475-0262 SIDE FIBRE BRICK PANEL - FOR BURNER
17 W080-0519 BOTTOM LOUVRE BRACKET
18 W335-0024 HOOD
19 W565-0058 CURTAIN MESH
20 W555-0033 CURTAIN ROD
21 W080-0357 CURTAIN ROD BRACKET
22 W630-0010 BLACK TASSELS
23 W500-0194 CURTAIN SUPPORT PLATE
24 N010-0279 SIDE LOUVRE HOOD W / LOUVRE BRACKETS
25 W200-0114 SIDE DOOR COVER
26 N010-0327 SIDE DOOR HEAT SHIELD
27 W475-0263 SIDE BRICK PANEL - FOR WALL
28 W500-0192 SIDE BRICK PANEL RETAINER
29 W335-0027 SHORT HOOD
30 W565-0060 SHORT CURTAIN MESH
31 W555-0039 SHORT CURTAIN ROD
32 N010-0310 END LOUVRE HOOD W / LOUVRE BRACKETS
33 W585-0126 END DOOR HEAT SHIELD
34 N010-0323 END DOOR COVER
35 W500-0192 END BRICK PANEL RETAINER
36 W475-0265 END BRICK PANEL
33 W585-0126 END DOOR HEAT SHIELD
34 N010-0323 END DOOR COVER
35 W500-0192 END BRICK PANEL RETAINER
36 W475-0265 END BRICK PANEL
29 W335-0027 SHORT HOOD
30 W565-0060 SHORT CURTAIN MESH
31 W555-0039 SHORT CURTAIN ROD
32 N010-0310 END LOUVRE HOOD W / LOUVRE BRACKETS
33 W585-0126 END DOOR HEAT SHIELD
34 N010-0323 END DOOR COVER
35 W500-0192 END BRICK PANEL RETAINER
36 W475-0265 END BRICK PANEL
329 W335-0027 SHORT HOOD
30 W565-0060 SHORT CURTAIN MESH
31 W555-0039 SHORT CURTAIN ROD
32 N010-0310 END LOUVRE HOOD W / LOUVRE BRACKETS
37 W010-0997 REPLACEMENT BURNER
38 W662-0001 NATURAL GAS OXYGEN DEPLETION SENSOR SYSTEM
38 W662-0002 PROPANE GAS OXYGEN DEPLETION SENSOR SYSTEM
39* W660-0005 BURNER ON/OFF SWITCH
40* W680-0004 THERMOPILE
41* W357-0001 PIEZO IGNITER
42 W455-0026 #38 NATURAL GAS BURNER ORIFICE
42 W455-0059 #53 PROPANE GAS BURNER ORIFICE
43 W725-0030 NATURAL GAS VALVE
43 W725-0031 PROPANE GAS VALVE
REPLACEMENTS
When ordering replacement parts always give the follow-
ing information:
1. M ODEL & S ERIAL N UMBER OF FIREPLACE
2. I NSTALLATION DATE OF FIREPLACE
3. P ART N UMBER
4. D ESCRIPTION OF PART
5. F INISH
6. T OP OR REAR VENT
COMPONENTS COMMON TO ALL UNITS
COMPONENTS UNIQUE TO OPEN END UNIT
COMPONENTS UNIQUE TO SEE-THRU UNIT
COMPONENTS UNIQUE TO PENINSULA UNIT
BURNER COMPONENTS
COMPONENTS UNIQUE TO ISLAND UNIT
ACCESSORIES
44 GVFLK LOUVRE KIT - BLACK
44 GVFLPB LOUVRE KIT - POLISHED BRASS
44 GVFLAB LOUVRE KIT - ANTIQUE BRASS
44 GVFLSS LOUVRE KIT - STAINLESS STEEL
45* BGDELK END LOUVRE KIT - BLACK
45* BGDELPB END LOUVRE KIT - POLISHED BRASS
45* BGDELAB END LOUVRE KIT - ANTIQUE BRASS
45* BGDELSS END LOUVRE KIT - STAINLESS STEEL
46 L36K LOUVRE KIT - UPPER & LOWER - BLACK
47* ELB40K END LOUVRE KIT - BLACK
48 HOIG-1 HERITAGE ORNAMENTAL INSET- GOLD PLATED
48 HOIKG-1 HERITAGE ORNAMENTAL INSET- BLACK GOLD PLATED
48 HOIBC-1 HERITAGE ORNAMENTAL INSET- BRUSHED COPPER PLATED
48 HOIBG -1 HERITAGE ORNAMENTAL INSET- BRUSHED GOLD PLATED
49* EHOIG -1 END HERITAGE ORNAMENTAL INSET- GOLD PLATED
49* EHOIKG-1 END HERITAGE ORNAMENTAL INSET- BLACK GOLD PLATED
49* EHOIBC-1 END HERITAGE ORNAMENTAL INSET- BRUSHED COPPER PLATED
49 EHOIBG -1 END HERITAGE ORNAMENTAL INSET - BRUSHED GOLD PLATED
50 DOIG-1 DIAMOND ORNAMENTAL INSET - GOLD PLATED
50 DOIKG-1 DIAMOND ORNAMENTAL INSET - BLACK GOLD PLATED
50 DOIBC-1 DIAMOND ORNAMENTAL INSET - BRUSHED COPPER PLATED
50 DOIBG-1 DIAMOND ORNAMENTAL INSET - BRUSHED GOLD PLATED
51* EDOIG-1 END DIAMOND ORNAMENTAL INSET - GOLD PLATED
51* EDOIKG-1 END DIAMOND ORNAMENTAL INSET - BLACK GOLD PLATED
51* EDOIBC-1 END DIAMOND ORNAMENTAL INSET - BRUSHED COPPER PLATED
51* EDOIBG-1 END DIAMOND ORNAMENTAL INSET - BRUSHED GOLD PLATED
52 GOIG-1 GOTHIC ORNAMENTAL INSET - GOLD PLATED
52 GOIKG-1 GOTHIC ORNAMENTAL INSET - BLACK GOLD PLATED
52 GOIBC-1 GOTHIC ORNAMENTAL INSET - BRUSHED COPPER PLATED
52 GOIBG-1 GOTHIC ORNAMENTAL INSET - BRUSHED GOLD PLATED
53* EGOIG-1 END GOTHIC ORNAMENTAL INSET - GOLD PLATED
53* EGOIKG-1 END GOTHIC ORNAMENTAL INSET - BLACK GOLD PLATED
53* EGOIBC-1 END GOTHIC ORNAMENTAL INSET - BRUSHED COPPER PLATED
53* EGOIBG-1 END GOTHIC ORNAMENTAL INSET - BRUSHED GOLD PLATED
54 SOIG-1 SEASHELL ORNAMENTAL INSET - GOLD PLATED
54 SOIKG-1 SEASHELL ORNAMENTAL INSET - BLACK GOLD PLATED
54 SOIBC-1 SEASHEL ORNAMENTAL INSET - BRUSHED COPPER PLATED
54 SOIBG-1 SEASHELL ORNAMENTAL INSET - BRUSHED GOLD PLATED
55* ESOIG-1 END SEASHELL ORNAMENTAL INSET - GOLD PLATED
55* ESOIKG-1 END SEASHELL ORNAMENTAL INSET - BLACK GOLD PLATED
55* ESOIBC-1 END SEASHEL ORNAMENTAL INSET - BRUSHED COPPER PLATED
55* ESOIBG-1 END SEASHELL ORNAMENTAL INSET - BRUSHED GOLD PLATED
56 EOIG-1 ECLIPSE ORNAMENTAL INSET - GOLD PLATED
56 EOIKG-1 ECLIPSE ORNAMENTAL INSET - BLACK GOLD PLATED
56 EOIBC-1 ECLIPSE ORNAMENTAL INSET - BRUSHED COPPER PLATED
56 EOIBG-1 ECLIPSE ORNAMENTAL INSET - BRUSHED GOLD PLATED
57* EEOIG-1 END ECLIPSE ORNAMENTAL INSET - GOLD PLATED
57* EEOIKG-1 END ECLIPSE ORNAMENTAL INSET - BLACK GOLD PLATED
57* EEOIBC-1 END ECLIPSE ORNAMENTAL INSET - BRUSHED COPPER PLATED
57* EEOIBG-1 END ECLIPSE ORNAMENTAL INSET - BRUSHED GOLD PLATED
58* W323-K STANDARD DOOR ASSEMBLY - FOR FACE C / W HOOD
59* W324-K STANDARD DOOR ASSEMBLY - FOR END C / W HOOD
FOR FOR FOR FOR FOR WARRANTY WARRANTY WARRANTY WARRANTY WARRANTY REPL REPL REPL REPL REPLA A A A ACEMENT CEMENT CEMENT CEMENT CEMENT P P P P PAR AR AR AR ARTS TS TS TS TS , , , , ,
A A A A A PHO PHO PHO PHO PHOT T T T TOCOPY OCOPY OCOPY OCOPY OCOPY OF OF OF OF OF THE THE THE THE THE
ORIGINAL ORIGINAL ORIGINAL ORIGINAL ORIGINAL INVOICE INVOICE INVOICE INVOICE INVOICE WILL WILL WILL WILL WILL BE BE BE BE BE REQUIRED REQUIRED REQUIRED REQUIRED REQUIRED TO TO TO TO TO HONOUR HONOUR HONOUR HONOUR HONOUR THE THE THE THE THE CLAIM CLAIM CLAIM CLAIM CLAIM
.....
*
IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED
.
FOR FURTHER INFORMATION
,
CONTACT YOUR NAPOLEON DEALER
.
