11
Lightning 1000 Installation Guide
Lightning Hardware
The following topics are covered in this section:
•
Chassis Dimensions
•
Chassis Front Components
•
Chassis Rear Panel Components
•
Chassis Backplane Components
•
Chassis Internal Components
•
ShotBox Components
•
Rear ShotBox Components
Chassis Dimensions
The Lightning Chassis is 7.0 inches (178 mm) or 4 rack units high, 17.0
inches (432 mm) wide and 24.5 inches (622 mm) deep.
17.0"
24.5"
7.0"
The Chassis is designed for rack-mounting in a standard equipment rack.
All video and control connections are located on the rear of the Chassis.
Refer to the
Signal Connection section for input/output connection details.
