8 Breaker [BREAKER]
If the breaker is operated due to over-current or the like, check the cause and eliminate
the trouble, then press the breaker button.
9 Zoom/Focus Connector [ZOOM/FOCUS]
Used to connect the zoom/focus control cables of lens.
6 Camera mounting hole (1/4-20UNC)
7 Camera mounting hole (3/8-16UNC)
The screw holes can be used to secure the camera for installing it on camera housing,
and when using a pan/tilt head or a tripod.
Major Operating Controls and Their Functions
_ Side Panel
: SDI Output Connectors [SDI OUT 1, 2]
SDI signal output is given by two lines.
; Interface Connector [I/F]
1
2
3
4
5
6
7
8
9
10
11 12
B R E A K E R
Z O O M /
F O C U S
S D I O U T
1
2
1 / F
8
9
;
:
TXD: Data from Camera to remote controller
RXD: Data from remote controller to camera
1
7
2
3
4
5
6
8
9
10
11
12
13
14
15
Pin No.
1
2
3
4
5
6
7
Signal
Y signal output
Pb signal output
Pr signal output
Sync signal input
DC 12V
Frame GND
TXD (H)
Pin No.
8
9
10
11
12
13
14
15
Signal
Y signal GND
Pb siganl GND
Pr signal GND
Sync signal GND
DC GND
TXD (C)
RXD (H)
RXD (C)
Pin No.
1
2
3
4
5
6
Signal
Focus control selection
Zoom control selection
GND
Forcible iris closing
Iris control
i Voltage
Pin No.
7
8
9
10
11
12
Signal
COM
Focus control
Zoom control
Iris control selection
COM iVoltage
COM jVoltage
