25
S GAIN 1
TOTAL GAIN :62dB
ANLG GAIN :36dB
PIX MIX :06dB
V MIX :OdB
FRAME MIX :20dB
H DTL LVL :00
CRISP :0
LEVEL DEPENDENT :5
PEAK FREQUENCY :2
M GAMMA :0.45
MASTER PED OFFSET :-043
R PED OFFSET :-046
B PED OFFSET :-045
°° °°
°
H FRAME MODE
1.SCAN REVERSE :OFF ° °
Setting of Menu Items
7 Super gain, Detail, Pedestal-offset
level setting menu
TOTAL GAIN: Total gain in analog, pixel
addition, and memory addition is dis-
played.
ANLG GAIN: Gain setting in analog.
PIX MIX: Gain setting in horizontal pixel
addition. Capable of setting 0/6 dB.
V MIX: Gain setting in vertical pixel addi-
tion. Capable of setting 0/6 dB.
FRAME MIX: Gain setting in memory ad-
dition. Capable of setting 0/6/12/15/20
dB.
H DTL LVL: DTL level setting of super
gain.
CRISP: Setting the function of reducing
noise level of super gain. It is invalid
when DTL level is “0.”
LEVEL DEPENDENT: Setting of DTL
suppression at low lighting intensity of
super gain.
PEAK FREQUENCY: Setting of DTL
boost frequency of super gain.
M GAMMA: Gain setting in super gain.
Capable of setting 0/6 dB.
MASTER PED OFFSET: Setting of mas-
ter pedestal offset of super gain 1.
R PED OFFSET: Setting of R pedestal
offset of super gain.
B PED OFFSET: Setting of B pedestal
offset of super gain.
! Maintenance menu
8 Setting menu in frame mode
SCAN REVERSE: Capable of changing
the right and left pictures, the top and bot-
tom pictures with each other, respectively.
(Super gain 1, 2, 3 are same menu.)
