EN
41
Statistics (Superframes represent the highest level of data presentation. Each superframe
contains regular ADSL frames, one of which is used to provide superframe
synchronization, identifying the start of a superframe. Some of the remaining frames
are also used for special functions.)
• Received cells Number of cells received.
• Transmitted cells Number of cells transmitted.
Start IP Address Specify the start IP address of the DHCP pool. Do not include the gateway address
of the ADSL Wireless Base Station in the client address pool. If you change the pool
range, make sure the first three octets match the gateway's IP address, i.e.,
192.168.2.xxx.
Status • Line Status Shows the current status of the ADSL line connection.
• Link Type Two types of link: Fast path and Interleaved path.
Status Provides WAN connection type and status, firmware and hardware version numbers,
system IP settings, as well as DHCP, NAT, and firewall information. Displays the
number of attached clients, the firmware versions, the physical MAC address for each
media interface, and the hardware version and serial number. Shows the security and
DHCP client log.
Subnet Mask Enter the subnet mask of the remote network for which to set a static route.
System Sets the local time zone, the password for administrator access, and the IP address of
a PC or notebook that will be allowed to manage the ADSL Wireless Base Station
remotely.
TCP SYN wait Default 30 sec:Defines how long the software will wait for a TCP session to
synchronize before dropping the session.
TCP FIN wait Default 5 sec: Specifies how long a TCP session will be maintained after the firewall
detects a FIN packet.
TCP connection idle timeout Default 3600 sec (1 hour): The length of time for which a TCP session will be
managed if there is no activity.
Total incomplete TCP/UDP sessions Default 300 sessions: Defines the rate of new unestablished sessions sessions that will
HIGH cause software to start deleting half-open sessions.
Total incomplete TCP/UDP sessions Default 250 sessions: Defines the rate of new unestablished sessions that will cause
LOW the software to stop deleting halfopen sessions.
UDP session idle timeout Default 30 sec:The length of time for which a UDP session will be managed if there is
no activity.
Valid Enables/disables the entry.
Version Sets the RIP (Routing Information Protocol) version to use on this interface.
Version Sets the trap status to disabled, or enabled with V1 or V2c.
The v2c protocol was proposed in late 1995 and includes enhancements to v1 that
are universally accepted. These include a get-bulk command to reduce network
management traffic when retrieving a sequence of MIB variables, and a more
elaborate set of error codes for improved reporting to a Network Management
Station.
VPI/VCI Virtual Path Identifier (VPI) and Virtual Circuit Identifier (VCI).
WAN Specifies the Internet connection settings.
WEP Mode Select 64 bit or 128 bit key to use for encryption.
Wireless Configures the radio frequency, SSID, and security for wireless communications.
Wireless Mode This device supports both 11g and 11b wireless networks.
Make your selection depending on the type of wireless network that you have.
Quiet Period Defines a maximum period of time for which the ADSL Wireless Base Station will
wait between failed authentications.
802.1X Authentication Enable or disable this authentication function.
