Philips DGX220 - Manual (Page 2)

DGX220/00
Specifications Product highlights
Multimedia Speaker 2.0
Digital Retail Version Bulk version
Date of issue 2007-02-20
Version: 6.0
12 NC: 9082 100 02969
EAN: 87 10895 81929 9
© 2007 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
Sound
• Bass enhancement: Dynamic ultra bass
• Music power: 4 W
• Output power (RMS): 2 x 1W
• Sound enhancement: Auto volume leveller,
Balance, Class "D" digital amplifier, EQ by genre,
Graphic equaliser
• Volume Control: digital
• Wires: Fixed wires
Loudspeakers
• Loudspeaker enhancement: Magnetic shielded
LSB
• Satellite speaker freq range: 120-20000Hz Hz
Connectivity
• Cable length: 1.2 m
• Connector: USB 'A' plug
• Headphone: 3.5 mm
• Microphone: Microphone socket
• Power: USB bus power
• USB: USB 2.0
Convenience
• Power on indication
Accessories
• Included accessories: Installation CD, Quick
install guide
Software
• Philips Sound Agent 2
System Requirements
• CD-ROM drive
• Hard disc space: 20 MB
• PC OS: Windows® 2000 or XP
• Processor: 350 MHz processor or better
• RAM memory: 64 MB
• USB: Free USB port
Power
• Power LED indicator: Blue
•
Home audio quality on the PC
Philips has used over 75 years experience at the leading
edge of audio to create PC audio products with the
same performance as our award winning home audio
systems.
75 years of audio experience
Philips invented the CD, led the team that wrote the
USB audio specification and has produced millions of
audio systems, home cinema sets and TV's over many
decades. As a leader in audio innovation, you can trust
Philips to make PC sound systems of the highest sound
quality.
Digital sound quality
Audio is transferred as a digital signal and only at the
last minute is it converted to an analogue signal. This
reduces the amount of interference on the signal and
results in playback that is true to the original recording.
Sound Agent 2
Sound Agent 2 is intelligent software that comes with a
fun and easy-to-use graphical interface. It takes the
confusion out of PC audio by automatically optimising
sounds for all popular formats. Sound Agent 2 makes it
easy to fine-tune any audio performance to suit your
personal musical taste.
Class D Amplifier
Class ‘D’ digital amplifier takes an analogue signal,
converts it into a digital signal and then amplifies the
signal digitally. The signal then enters a demodulation
filter to give the final output. The amplified digital
output delivers all the advantages of digital audio,
including improved sound quality. In addition, Class ‘D’
digital amplifier has greater than 90% efficiency
compared to traditional AB amplifiers. This high
efficiency translates into a powerful amplifier with a
small footprint.
Music, games, films, Internet
All types of music, games, films and Internet audio
sources can be played, so no matter what you want to
hear, we make your multimedia experiences sound
more involving than ever.
For PC or laptop
Can be connected to either a PC or a laptop
Bass reflex speaker system
Bass reflex speaker system delivers a deep bass
experience from a compact loudspeaker box system. It
differs from a conventional loudspeaker box system in
the addition of a bass pipe that is acoustically aligned to
the woofer to optimise the low frequency roll off of the
system. The result is deeper controlled bass and lower
distortion. The system works by resonating the air mass
in the bass pipe to vibrate like a conventional woofer.
Combined with the response of the woofer, the system
extends the overall low frequency sounds to create a
whole new dimension of deep bass.
Ultra Bass
Ultra Bass, a patented Philips technology, dramatically
improves the perceived bass response of small
speakers. It seeks out and plays the harmonics found in
ultra low bass frequencies to deliver sound quality that
far exceeds your expectations.
MP3 Energy Boost
When CD's are ripped to MP3, some of the dynamics
are lost due to compression. MP3 Energy Boost
dynamically analyses MP3 and WMA files and adds
frequencies that were lost during compression. The
result is more defined and realistic MP3's that are closer
to the original CD track.
