Useful Information

For assistance, please visit http://www.panasonic.com/phonehelp

Charger

The charger can be mounted on the wall.
Drive the screws (not included) into the
wall using the wall template as a guide,
then mount the charger securely on the
screws.
Connect the AC adaptor to power outlet
(page 16).

Note:

Make sure the screws are securely
fastened to the wall.

Belt clip

You can hang the handset on your belt or
pocket using the included belt clip.

To attach the belt clip

To remove the belt clip

(120 V AC,
60 Hz)

Screws

25.2 mm
(1 inch)

Wall mount template for the charger

25.2 mm

(1 inch)
