APPENDIX A

MODEL 3004-MTE SERIES

TECHNICAL SPECIFICATIONS

Connection:

Tail circuit, DCE to DCE

Wiring:

Internal "cross-over" wiring

Transmission format::Synchronous, transparent to protocol

Data rate:

Up to 2.304 Mbps

Functional interface: 3004-MTE/V.35- CCITT V.35

3004-MTE/530- EIA/RS-530

3004-MTE/V.36- EIA/RS-449

Electrical/Physical
Interface:

3004-MTE/V.35- V.35 compatible. Male or
female 34-pin V.35 connectors on 6 foot cables

3004-MTE/530- RS-422/V.11 compatible. Male or
female 25-pin D-sub connectors on 6 foot cables

3004-MTE/V.36- RS-422/V.11 compatible.

Male or female 37-pin D-sub connectors on 6
foot cables

Tail-to-system
Buffering:

Single, auto-centering 64-bit buffer

Powering:

Derived from data, clock and control signals. No

external power required.

Environment:

0-60°C, 32-140°F, humidity up to 95%, non-
condensing

Dimensions:

3.0"L x 1.7"W x 0.8"H

APPENDIX B

PATTON ELECTRONICS MODEL 3004-MTE/V.35

INTERFACE PIN ASSIGNMENT

V.35 Interface

Pin #

Signal

A............................FG

(Frame Ground)

B............................SGND

(Signal Ground)

C ...........................RTS

(Request to Send)

D ...........................CTS

(Clear to Send)

E ...........................DSR

(Data Set Ready)

F............................CD

(Carrier Detect)

H ...........................DTR

(Data Terminal Ready)

P ...........................TD

(Transmit Data-A)

R ...........................RD

(Receive Data-A)

S ...........................TD/

(Transmit Data-B)

T............................RD/

(Receive Data-B)

U ...........................XTC

(External Transmit Clock-A)

V ...........................RC

(Receive Timing-A)

W ...........................XTC/

(External Transmit Clock-B)

X ...........................RC/

(Receive Timing-B)

Y ...........................TC

(Transmit Timing-A)

AA ..........................TC/

(Transmit Timing-B)
