Connections
12
Connect AV Output Terminals
Connect the Audio/Video cables between the Audio (L/R)/Video jacks on the unit and VCR.
To record the desired program, please select a program you wish to record firstly, then turn on your VCR,
insert videotape for recording and press the Record button to begin recording.
Note: The AV output terminals output the audio/video signal from the Antenna input or AV inputs.
VCR for recording
To video
input
To video
output
To audio
inputs
To audio
outputs
Yellow (video)
White (audio L)
Red (audio R)
W
Y
R
