5 1 3 2 4 5 1 3 4 2
6.6"
(16.7 cm)
4"
(10.2 cm)
7.5"
(19.2 cm)
9.1"
(23.2 cm)
A
B
5 1
3 2 4
5 1
3 4 2
TOGGLE SWITCH
Set number of addresses
per fixture.
DISPLAY
Number of addresses per fixture
TOGGLE SWITCH
Set light address
DISPLAY
Light address
TEST BUTTON
DMX DATA IN
RJ45 OR XLR-5
DMX DATA OUT
RJ45 OR XLR-5
DATA
INDICATOR
A
ACCESSORY
POWER JACK
5.10”
(13.9 cm)
7.54”
(19.2 cm)
4.79”
(12.2 cm)
7.73”
(19.6 cm)
3.31”
(8.4 cm)
1.18"
(3.0 cm)
1.20"
(3.0 cm)
1.18"
(3.0 cm)
1.18"
(3.0 cm)
1.06"
(2.7 cm)
R0.25"
(0.6 cm)
0.20"
(0.5 cm)
B
OPTIONAL MOUNTING BRACKET
FOR T-HANDLE MOUNING
8.97”
(22.7 cm)
68.583"
60 lb (27 kg)
IEC 15A (max) with C13 plug
100-240VAC (420W) weight ( approx )
power cable
power requirement
colorblaze 72
iteM# 116-000015-00/01
CoLoRBLAze 72
physical dimensions
