NXP Semiconductors
Product data sheet
Quadruple ESD transient voltage
suppressor
BZA800AL series
handbook, halfpage
10
1
10
−
1
MLD790
10
−
2
10
−
1
1
tp (ms)
IZSM
(A)
10
BZA856AL
BZA862AL
BZA868AL
Fig.2
Maximum non-repetitive peak reverse
current as a function of pulse time.
handbook, halfpage
1
10
10
2
MLD791
10
−
2
10
−
1
1
tp (ms)
PZSM
(W)
10
BZA856AL
BZA862AL
BZA868AL
Fig.3
Maximum non-repetitive peak reverse
power dissipation as a function of pulse
duration (square pulse).
P
ZSM
= V
ZSM
× I
ZSM
.
V
ZSM
is the non-repetitive peak reverse voltage at I
ZSM
.
handbook, halfpage
0
2
VR (V)
Cd
(pF)
4
8
120
0
40
80
6
MLD792
BZA856AL
BZA862AL
BZA868AL
Fig.4
Diode capacitance as a function of reverse
voltage; typical values.
T
j
= 25
°C; f = 1 MHz.
handbook, halfpage
0
50
Tamb (
°
C)
Ptot
(mW)
100
150
400
300
100
0
200
MLD793
Fig.5 Power derating curve.
