Input Video Adjustments [Picture 2]
Pan
Adjustment of Screen Display Position
This is used to adjust the screen position at the time
of DVI input selection.
Press the cursor button (
↑↓
) and align the cursor with
[Screen Movement], then press the SET button. The
menu display will close and the cursor display will ap-
pear.
Zoom Filter
0
Gamma
- Pan -
Custom Graphics Film Video
Picture2 Setup Info.
DVI
Option
Position
Gamma
Gamma Settings
These are settings of the tone of the image.
Press the cursor (
↑↓
) button and align the cursor with
[Gamma], then select with the cursor (
← →
) button.
Video: This is a gamma adjustment value suited to video
signals.
Film: This is a gamma adjustment value suited to movies.
Graphics: This is a gamma adjustment value suited to
graphics such as computer images.
Custom adjustments
This adjustment permits the creation of a desired
gamma curve.
This is performed while viewing the target image.
Select [Custom] with the cursor (
← →
) button, then
press the SET button.
The custom adjustment screen will be displayed.
1. Press the cursor ( ← → ) button and align the cursor
with the index.
2. Select the adjustment point with the cursor (
← →
) but-
ton.
3. Select the color that is to be adjusted with the cursor
(
↑↓
) button, then adjust with the cursor (
← →
) but-
ton.
When required, adjust other adjustment points in the
same manner.
Video Filter
2
2
Zoom Filter
Video Auto ProScan Mode
Gamma Custom Graphics Film Video
Color System Auto
Picture2 Setup Info.
VIDEO
Option
Video Filter
Zoom Filter
ProScan Mode
Gamma Custom Graphics Film Video
Color System
Picture2 Setup Info.
VIDEO
Option
Index 1
Red 7
Green 7
Blue 7
Note: See → Page E-37 "Return-
ing to Standard Settings" for infor-
mation about returning to the stan-
dard setting values. Note that other
adjustments and settings will also
be reset.
Note: This adjustment is possible
only when an image larger than S-
VGA is displayed with THRU.
Note: Index (1 to 31) indicates ad-
justment point of a 32nd part of
input values between 0 and 255.
