4
Chapter 2. Using the Router
2.1 Cautions for using the ADE-4120
Do not place the ADE-4120 under high humidity and high temperature.
Do not use the same power source for ADE-4120 with other equipment.
Do not open or repair the case yourself. If the ADE-4120 is too hot, turn off
the power immediately and have a qualified serviceman repair it.
Place the ADE-4120 on a stable surface.
Only use the power adapter that comes with the package.
2.2 The Front Panel LEDs
ADE-4120
LED Meaning
PWR Lit when power ON
POST Blinks when the device is booting
ADSL Lit when successfully connected to an ADSL DSLAM
READY Lit when the device is ready to use
LNK/ACT Lit when connected to Ethernet device
Blinks when data transmit/received
100 Lit when connected at 100Mbps speed
LAN port
1 ~ 4
FDX/COL Lit when connected at Full Duplex and blinks when there
is collision.
