System overview
Note: for more detailed information on LED Drivers, LED Modules and LED String ask for specific product data sheets.
Xitanium™ is a registered trademark of Philips Electronics NV.
Luxeon™ is a registered trademark of Lumileds.
For more information:
Philips Lighting BV
Mathildelaan 1
5611 BD Eindhoven
Tel.: +31 40 2755893
Fax.: +31 40 2756038
Data subject to change
.
Printed in the Netherlands.
3222 635 4989
1 * NO
V 2004
Input Output
Specifications
Ordering Information
12W indoor 207 - 264 15.0 0.14 12.0 350 +/- 5% 2.6 - 33.0 85
17W indoor 207 - 264 21.5 0.20 17.1 700 +/- 5% 2.6 - 24.6 85
25W indoor 207 - 264 31.9 0.30 25.5 1050 +/- 5% 2.6 - 24.6 85
25W DIM indoor 207 - 264 31.9 0.30 25.5 1050 +/- 5% 14 - 24.0 85
40W indoor 207 - 264 51.0 0.47 40.8 1750 +/- 5% 2.6 - 24.0 85
12W outdoor 207 - 264 15.0 0.14 12.0 350 +/- 5% 2.6 - 33.0 90
17W outdoor 207 - 264 21.5 0.20 17.1 700 +/- 5% 2.6 - 24.6 90
40W outdoor 207 - 264 51.0 0.47 40.8 1750 +/- 5% 2.6 - 24.0 50
67W outdoor 207 - 264 80.0 0.40 67.2 2800 +/- 5% 2.6 - 25.0 90
80W outdoor 207 - 264 95.0 0.50 80.0 3300 +/- 5% 2.6 - 25.0 90
Description
LED Driver
Voltage
V
Max. power
W
Max. current
A
Max. power
W
Current
A
Voltage
V
Tc max.
12W indoor 10 749963 30
17W indoor 10 749987 30
25W indoor 12 927361 30
25W DIM indoor 12 927408 30
40W indoor 12 927385 30
Description LED Driver Box
packaging
EOC
12W outdoor 10 930453 30
17W outdoor 10 930958 30
40W outdoor 3 931221 30
67W outdoor 20 931207 30
80W oudoor 20 931245 30
Description LED Driver Box
packaging
EOC
Quick selection table
Description Configuration options
12W 350mA - 1-8 one-watt Luxeons
- max. 3.2m Philips LED String Red & Amber
- max. 3.5m Philips LED String Blue & Green
17W 700mA - 6, 8, 10 or 12 one-watt Luxeons
- 6-up and 12-up Luxeon lines, rings or arrays
- 1-5 three-watt Luxeons
- 1-3 five-watt Luxeons
- max. 5.0m Philips LED String Red & Amber
- max. 4.2m Philips LED String Blue & Green
- 1-10 Philips LED Modules
Description Configuration options
25W 1050mA - 3, 6, 9, 12, 15 or 18 one-watt Luxeons
(indoor only) - 18-up Luxeon array
- 1-5 three-watt at 1.0A Luxeons
25W 1050mA - 15 or 18 one-watt Luxeons
Dimming
(indoor only)
40W 1750mA - 5, 10, 15, 20, 25 or 30 one-watt Luxeons
- Philips LED String White max. 4.0m
- 1-24 Philips LED Modules
67W 2800mA - 8, 16, 24, 32, 40 or 48 one-watt Luxeons
(outdoor only) - 4, 8, 12, 16 or 20 three-watt Luxeons
80W 3150mA - 9, 18, 27, 36, 45 or 54 one-watt Luxeons
(outdoor only) - 5, 10, 15 or 25 three-watt Luxeons
