Page 8: Keyboard dip switch dip switch cover plate
6
Pelco Manual C527M (11/97)
Figure 3. Keyboard Cabling Diagram
1 2 3 4
KEYBOARD
DATA
KEYBOARD
DIP SWITCH
DIP SWITCH
COVER PLATE
Figure 4. Keyboard Rear Panel
VIDEO INPUTS
1
3
5
7
9
11
13
15
2
4
6
8
10
12
14
16
VIDEO OUTPUTS
1
2
3
4
CM6700 SCU
WALL
TRANSFORMER
SCU
WALL JACK
6' CABLE
10' CABLE
KBD
KBD
ADDITIONAL
KEYBOARDS
AS NEEDED
USER SUPPLIED
CABLE (SEE FIGURE 2)
SWITCHER/CONTROLLER
DATA CABLE
KEYBOARD
DATA CABLE
PIN
FUNCTION
1
TxD+
2
TxD-
3
12 VAC/DC
4
NON POLAR
5
GND
6
7
RxD-
8
RxD+
PIN 1
KBD300 RJ-45
CONNECTOR
}
