2.0 DESCRIPTION
The KBD300 keyboard provides complete programming and operational control of
the CM6700 Matrix Switcher. This keyboard features a three axis joystick that in-
cludes a twisting, return-to-center head for full control of variable speed pan, tilt and
zoom fuctions.
Included in this package:
Qty Description Pelco Part Number
1 KBD300 Keyboard, 120 VAC, or KBD300
KBD300 Keyboard, 230 VAC KBD300-X
1 12 VAC wall mount transformer, 120 VAC, or TRF112.0S.20
12 VAC wall mount transformer, 230 VAC TRF212.0S.25
1 RJ-45 modular wall jack CON12J008Z03G0Z
1 Keyboard data cable WIRA220122
See the CM6700 Installation/Operation Manual (C523M-A) for detailed operating
instructions.
