4
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions are given in U.S. inches.
1 inch = 25.4 mm
FRONT TINE TILLER - - MODEL NUMBER RT900 (MFG. ID. NO. 96092002100)
MAINFRAME, LEFT SIDE
2 73970500 Locknut, Hex, Flange 5/16-18
5 102332X Bracket Reinforcement RH
7 102173X Counter Weight,
10 74760524 Bolt, Hex 5/16-18 x 1-1/2
11 4497H Clip, Hairpin
12 126875X Rivet, Drilled
13 102190X Tire
183122X428 Rim
795R Tire Valve
15 - - - - - - - - Engine, B&S Model No. 121002-1380-B8
(Order parts from engine manufacturer)
44 73510600 Nut, Keps, Hex 3/8-16 unc
MAINFRAME?RIGHT??R
