13
Chapter 5 Specifications
5.1 Cable Specifications
Ethernet Type Cable Requirements Maximum Length
10BASE-T Category 3 or better, UTP or STP 328 ft (100M)
100BASE-TX Category 5 or better, UTP or STP 328 ft (100M)
1000BASE-T Category 5e or better, UTP or STP 328 ft (100M)
There are two types of cables: Straight Through Cables and Cross-over Cables. Category 5 UTP/STP
cable has eight wires inside the sheath. The wires form four pairs. Straight Through Cables has same
pin-out at both ends while Cross-over Cables has a different pin arrangement at each end.
5.2 Technical Specifications
Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3x IEEE802.3ab
Protocol CSMA/CD
Connectors RJ-45
Bus Type CardBus
LEDs SPEED, LNK/ACT
Maximum Segment Length 100M (328 ft) over Category 5 twisted-pair cable
Cabling Requirements 4-pair, Category 5, Category 5 enhanced
Speed
10/100/1000 Mbps at Half duplex mode
20/200/2000 Mbps at Full duplex mode
5.3 Environmental Information
Dimensions 119 x 55 x 22.6 (L x W x H, mm)
Weight 45 g
Operating temperature 0° to 50°C
Storage temperature -20° to 70°C (-40° to 158°F)
Operating humidity 5% to 90% relative humidity, non-condensing
Storage humidity 5% to 90% relative humidity, non-condensing
5.4 Standard Conformance
EMC Certification FCC Class A, CE
