Bluetooth QuickStart Kit Version 1.0 - User’s Guide Page 24
Copyright 2004-2005 © Embedded Artists AB
OEMSPA-13i datasheet for details
about functionality.
This push-button should normally
never be used, and it is only active
during power-up of the Bluetooth
module.
RGB LED #1
This RGB LED is controlled from
the Bluetooth module and indicates
current status.
Green = Module is OK
Orange = Module is in AT-command mode
Blue = A connection is active
Flashing Blue = Data is transferred over the active
connection
Red = Reset or illegal AT-commands
received
RGB LED #2
This RGB LED is controlled by the
application program and can be used
for program debugging or showing
application status.
Table 1 – Board Interfaces
5.3 Bluetooth Modules
The Bluetooth connector (J9 in the schematic) supports four different versions in the OEM
Serial Port Adapter family from connectBlue, as listed in Table 2 below.
Name Size Bluetooth Data
OEMSPA13i 23 x 36 mm Class 2 / 0 dBm with internal antenna
It is this Bluetooth module that the Bluetooth
QuickStart Kit is shipped with.
OEMSPA13x 23 x 36 mm Class 2 / 0 dBm with external antenna
OEMSPA33i 40 x 42 mm Class 1 / 20 dBm with internal antenna
OEMSPA33x 40 x 42 mm Class 1 / 20 dBm with external antenna
Table 2 – OEM Serial Port Adapters
